안녕하세요.



오늘은 [2024][Juniper SRX #12] application and application-set입니다.



Juniper 방화벽 정책을 설정 시 Source port 또는 Destination port에 TCP/UDP, 또는 port number를 지정할 때 사용 합니다.

자세한 내용은 Juniper SRX 공식 홈페이지를 참조 바랍니다.

https://www.juniper.net/documentation/us/en/software/junos/security-policies/topics/topic-map/policy-application-sets-configuration.html



Security Policy Applications and Application Sets | Junos OS | Juniper Networks

When you create a policy, you must specify an application, or service, for it to indicate that the policy applies to traffic of that type. Sometimes the same applications or a subset of them can be present in multiple policies, making it difficult to manag

www.juniper.net



Applications은 두 가지로 분류됩니다.

1. standard

2. custom applications



standard way는 이미 Juniper SRX에서 정의된 포트를 말합니다. 주로 well-known port를 의미합니다.

set applications application standard-way application-protocol http

root# set applications application KK application-protocol ?
Possible completions:
  dns                  Domain Name Service
  ftp                  File Transfer Protocol
  ftp-data             File Transfer Protocol Data Session
  gprs-gtp-c           GPRS Tunneling Control Plane
  gprs-gtp-u           GPRS Tunneling User Plane
  gprs-gtp-v0          GPRS Tunneling Version 0
  gprs-sctp            GPRS Stream Control Protocol
  http                 Hypertext Transfer Protocol
  https                Hypertext Transfer Protocol
  ignore               Ignore application type
  ike-esp-nat          IKE/ESP with NAT
  imap                 Internet Mail Access Protocol
  imaps                Internet Mail Access Protocol Over TLS
  mgcp-ca              MGCP-CA
  mgcp-ua              MGCP-UA
  ms-rpc               Microsoft RPC
  none                 None
  pop3                 Post Office Protocol 3 Protocol
  pop3s                Post Office Protocol 3 Protocol Over TLS
  pptp                 Point-to-Point Tunneling Protocol
  q931                 Q.931
  ras                  RAS
  realaudio            RealAudio
  rsh                  Remote Shell
  rtsp                 Real Time Streaming Protocol
  sccp                 Skinny Client Control Protocol
  sip                  Session Initiation Protocol
  smtp                 Simple Mail Transfer Protocol
  smtps                Simple Mail Transfer Protocol Over TLS
  sqlnet-v2            Oracle SQL*Net Version 2
  ssh                  Secure Shell Protocol
  sun-rpc              Sun Microsystems RPC
  talk                 Talk Program
  telnet               Telnet Protocol
  tftp                 Trivial File Transfer Protocol
  twamp                Two Way Active Meaurement Protocol
[edit]



이번에는 custom 방식에 대해서 알아보겠습니다.

Protocol -> tcp

Source-port - 0-65535 -> source port는 랜덤으로 선택됩니다. 특정 Application은 source-port가 특정 포트로 동작하는 APP도 있습니다

Destination-port - 23

inactivity-timeout - 20초

set applications application telnet-1 protocol tcp
set applications application telnet-1 source-port 0-65535
set applications application telnet-1 destination-port 23
set applications application telnet-1 inactivity-timeout 20



방화벽 정책 설정 시 application를 아래처럼 불러와서 사용 가능 합니다.

set security policies from-zone trust to-zone untrust policy p1 match application telnet-1



만약에 하나에 방화벽 정책에 여러 개 application를 사용하고 싶으면 아래와 같이 설정 가능 합니다

set applications application http-1 protocol tcp
set applications application http-1 source-port 0-65535
set applications application http-1 destination-port 80
set applications application http-1 inactivity-timeout 20

아래처럼 application 정책을 계속 추가해야 합니다.

set security policies from-zone trust to-zone untrust policy p1 match application telnet-1
set security policies from-zone trust to-zone untrust policy p1 match application http-1



하지만 application-set을 이용하면 하나에 정책에 많은 application 추가해서 사용할 수 있습니다.



application-set에 http-1이랑 telnet-1을 할당합니다.

set applications application-set app-group application http-1
set applications application-set app-group application telnet-1



그리고 방화벽 정책에 application-set를 설정합니다.

set security policies from-zone trust to-zone untrust policy p1 match application-set app-group



application 설정값 확인 하는 명령어

root> show configuration applications | display set
set applications application standard-way application-protocol http
set applications application http-1 protocol tcp
set applications application http-1 source-port 0-65535
set applications application http-1 destination-port 80
set applications application http-1 inactivity-timeout 20
set applications application telnet-1 protocol tcp
set applications application telnet-1 source-port 0-65535
set applications application telnet-1 destination-port 23
set applications application telnet-1 inactivity-timeout 20
set applications application-set app-group application http-1
set applications application-set app-group application telnet-1

root>



지금까지 [2024][Juniper SRX #12] application and application-set 글을 읽어주셔서 감사합니다.
